What are the applications of Poe technology in the industrial field?

2023-04-28

Power over Ethernet (POE) is a dual function technology of standard Ethernet cabling, which is used not only as a data transmission facility, but also as a means of supplying power to remote equipment. The emergence of this technology provides many advantages in simplifying installation and improving interconnection efficiency. Common devices used in this technology include: IP phones, security cameras, intelligent lighting devices, modern intelligent office equipment and other devices, which can use Poe technology to complete equipment power supply. In this way, the cost of configuring the power cord can be saved, and the whole device is simpler and cheaper.

The same is true for industry. Transmitting power through Ethernet cables requires fewer cables to be laid on the facility, making it easier to establish or reconfigure production sites. At present, Poe technology has extended from traditional WLAN, network monitoring, IP phone and other fields to new retail, IOT, smart city and other new application scenarios. This technology has the characteristics of low cost, convenient construction, stable power supply and high operation and maintenance efficiency.

ZXR016FP

16-port 10/100-TX Industrial PoE Switch

ZXR016FP an hardened 16-port Industrial PoE Switch, provides non-blocking wire-speed performance in harsh industrial environment. It also provides 16-port 10/100-TX RJ45 copper interfaces delivered in an IP40 rugged, strong case with redundant power system. Its slim case is suitable for such applications as surveillance system deployments, control management and wireless service in climatically demanding environments with wide temperature range from -40℃ to 80℃.

The ZXR016FP series is packaged in a compact IP40 case that allows DIN rail to have efficient usage of cabinet space. It provides an integrated power supply with a wide range of voltages for worldwide operation. It also offers dual-redundant, reversible polarity 48V DC to 57V DC power supply inputs for

high availability applications requiring dual or backup power inputs.

Industrial conformance

• 48V to 57V DC, redundant power input

• -40℃ to 80℃ operating temperature

• IP40 aluminum housing

• Supports Air discharge: ±12kV

• Contact discharge: ±8kV

• Free Fall, Shock and Vibration Stability

• DIN-rail hardware design

Specifications:

Model No.	ZXR016FP
10/100-TX Port	16 port RJ-45 auto-MDI / MDI-X
PoE Specification	PoE Standard: IEEE802.3af/ IEEE802.3at
	PoE ports:1-16 port support PoE
	Power Output: Max. 15.4 watts (IEEE 802.3af) Max. 30 watts (IEEE 802.3at)
	PoE port Auto detect IEEE 802.3 af/at devices
	Output Voltage: DC48V
	Power Pin Assignment:1/2+;3/6-
	Power Type: End-span( Mid-span optional)
Performance Specification	Bandwidth: 3.2Gbps Packet Buffer Memory:4Mbit Packet Forwarding Rate: 2.4Mpps MAC Address Table: 8K
Installation	DIN rail
Maximum Frame Size	2000bytes packet size
Flow Control	Back pressure for half duplex, IEEE 802.3x pause frame for full duplex
Enclosure	IP40 aluminum housing
LED Indicator	Power: Red Ethernet: Yellow POE: Green
Power Input	48 to 57V DC redundant power
Surge protection	±4KV
Network Protocols	IEEE802.3 10BASE-T IEEE802.3i 10Base-T IEEE802.3u;100Base-TX IEEE802.3x
Network cables	10BASE-T: Cat3,4,5 UTP(≤100 meter) 100BASE-TX: Cat5 or later UTP(≤10meter)
Industry Standard	EMI ：FCC Part 15 Subpart B Class A，EN 55022 Class A EMS : IEC(EN)61000-4-2(ESD) : ±8Kv contact discharge,±12kV air discharge IEC(EN)61000-4-3(RS) : 10V/m(80～1000MHz) IEC 61000-4-4 (EFT), Power cord ±4kV data cable:±2kV IEC 61000-4-5 (Surge), Ethernet port ±4kV CM//±2kV DM IEC(EN)61000-4-6(RF conduction) : 3V(10kHz～150kHz),10V(150kHz～80MHz) IEC(EN)61000-4-16(common conduction) : 30V cont. 300V,1s IEC(EN )61000-4-8 Shock: IEC 60068-2-27 Free fall: IEC 60068-2-32 Vibration: IEC 60068-2-6
MTBF	>300,000hours
Certification	CE FCC Rohs compliance
Dimensions (W x D x H)	175.6 x 135 x 45.5 mm
Weight	Product Weight: 1.1KGS Packing Weight: 1.2KGS
Working Environment	Working temperature: -40～80℃ ; Storage temperature: -40～80℃ Relative Humidity: 5%~95 %( no condensation)
Warranty	1-year replacement with new item; 3-years for main parts.
